The ViewEra V191HV 19”
TFT-LCD monitor with VGA, composite audio/video and S-Video
inputs will bring a digital view to your
desktop. The V191HV
produce super fast response time of
8 ms plus wide viewing angle of 150°,
high contrast ratio of 500:1 (typ) and
brightness of 270 cd/m² (typ). With S-video and composite video inputs, you can plug in a PS2, X-box, DVD player, VCR, digital camera or camcorder. In addition,
the V191HV delivers
resolution of 1280x1024 SXGA, plug and
play and two built-in speakers of 3
watts. The base stand and slim frame
design makes the monitor look compact
and simple. The V191HV
provides high digital quality, reliability
and space-saving 19” LCD monitor
for your personal entertainment. |
|
|
| Specification |
Model |
V191HV |
LCD
Display |
Glare type, 19” Active Matrix TFT LCD
Panel |
Max.
Resolution |
1280(H) x 1024(V)
SXGA |
Pixel
Pitch |
0.294mm |
Color
depth |
16.2 million |
Contrast
ratio |
Typical: 500 : 1 |
Brightness |
Typical: 270 cd/m² |
Viewing
angle |
Horizontal : 150° , Vertical
: 135° |
Response
time |
Typical: 8 ms |
| Wall mountable |
VESA 75 |
Signal
input |
D-sub VGA, Composite Video, S-Video |
Plug
& Play |
DDC 1 / 2 B |
Resolution
Support |
VGA, SVGA, XGA, SXGA |
Frequency |
(Horizontal) 30~82 KHz, (Vertical)
50~75Hz |
| Frequency Sync. |
H/V separated (TTL) Positive/
Negative |
Audio-in
(speaker) |
3W x 2 |
| Input Connector |
D-sub, DC In, Composite Audio/Video, S-Video and Audio line-in |
| Set color |
Silver |
Power
consumption |
50 Watt (Max.) |
Power
adapter |
AC Input: 100-240V~1.8A, 50-60HzDC
DC Output: 12V/4.0A (4.2A) |
| Front Control |
Power, OSD menu, Down, Up,
Image auto tuning |
OSD
Function |
Contrast, Brightness, Auto Image
Adjust, H. Position, H. Phase, V.
position, H. Width, Sharpness, Color
Temperature, OSD position, Language,
Recall, Volume |
Operating
Conditions |
Temperature: 5°C~35°C
/ Humidity: 20%~80% (non-condensing) |
Storage
Conditions |
Temperature: -20°C~60°C
/ Humidity: 10%~90%(non-condensing) |
| Set Size |
425(H) × 425(W) × 175(D)
mm |
| Weight |
Net:5.5 Kg / Gross:7.0 Kgs |
| Safety & EMI |
UL, CUL, FCC-B, CB, CE, TUV/GS |
| Warranty |
3 years parts and labor, 1 year LCD panel |
| Accessory |
Power adapter, power cord, VGA cable, audio cable, user manual |
|
|
| |
|
|
|
|
